A New type Agricultural Anti Dripping Film based on Fluorine carbon surfactant Technology

 This special agricultural Anti drip polyvinyl chloride film has excellent thermal stability and long-lasting ,anti-fogging ability.

The film comprises l00 parts of polyvinyl chloride, 0.01-0.7 part of fluorocarbon surfactant, 0.3-10 parts of organic phosphorus compound

Anti-fog agent 0.8 to 5 parts.

The detail specification  formula (parts by mass):

PVC (d.P.1300) 100

Megafac Fl42 D 0.3

Epoxy resin 2

(R1 ~ 4 = phCH2) 1

Ba-Zn Stabilizer 2.5

Sorbitan monostearate l

DOP 49

Sorbitan monopalmitate l

The above components are mixed and molded into a 0.1 mm thick film. Agricultural films with  drip-proof and anti-fog Performance .

, This agricultural film water absorption layer (made of thermoplastic polyoxyethylene polymer, the average molecular weight of 10,000 to 300,000)

And non-water-absorbing thermoplastic polymer containing anti-drip and anti-fogging agents. Fluorocarbon surfactants can be used as anti-fogging agents and anti-drip

Liquid agent.

 (2) Transparent anti-fog Fiber film ,with wetting  ability and anti-fogging , the    surface were modified by  fluorocarbon surfactant Agent. Fluorocarbon surfactant form a monolayer which covering the surface of the fiber membrane, the modification effect is more better than the non-fluorosurfactant

It is could be  evidenced by the contact angle and Zisman curve of water drop on the surface).  The Films (fluorocarbon surfactant added)

Which be placed  in a room full of water vapor (60 ℃), the experiment proved the film surface no fog in long time and remain transparent. Anti-fogging function from the fluorocarbon Monolayers which made from fluorocarbon surfactants consisting of chains and non-ionic oxyethylene chains.
